Roof tile cover
1 Timber
&
38 x 58 x 2430 mm
&
30 x 100 x 2430 mm
2 Roof hooks
3 Zinc-plated c ountersunk chip-
board screw (Spax-s) 6 x 80 mm
4 Zinc-plated c ountersunk chip-
board screw (Spax-s) 5 x 30 mm
Slate cover
5 Roof hooks
6 Zinc-plated c ountersunk chip-
board screw (Spax-s) 6 x 30 mm
Corrugated sheet cover
7 Roof hooks f or corrugated roo fing
sheet profile 5 and 6
8 Roof hooks f or corrugated roo fing
sheet profile 8
Plain tile cover
9 Roof hooks
4 Zinc-plated c ountersunk chip-
board screw (Spax-s) 5 x 30 mm
Fixing kit without roof hooks
qP Mounting bracket
For all forms of roof and roofing
qQ Cl amping brack et
qW T-slot bolt
qE Washer
qR Hexagon nit
qT Mounting rail
qZ Mounting rail with tube holder
qU Retaining plate
qI Locking profile
qO Spacer
wP Co nnecting cham ber
wQ Vacuum tube
wW Retaining rubber
Accessories for one collector array
wE Connecting pipe
wR Retaining clip
Connection set:
wT Connecting pipe (short)
wZ Connecting pipe (long)
wU Profile clip
wI Locking ring fitting (elb ow 90°),
7 22 mm
wO Support sleev e
eP U-pipe
eQ Thermal insulati on cap
eW Fixing screws
Accessories for a solar heating
system
wO Support sleeve
eE Lockingringfitting(tee),
7 22 mm
eR Sensor well
eT Strain relief fitting
eZ Thermal insulation
Horizontal rooftop installation (cont.)
6
5862 788 GB
