Vitorond 100, VR1 22 to 33, 91 to 140 Installation and Service
5583 571 - 05
18
Connections
Safety Connections (with Hydrostat 3250-Plus Control) (continued)
1. To avoid problems with removing the top panel,
we recommend moving the top panel screw
approximately 3” to the left or right. To do so,
pre-drill the panel with an
d” drill bit.
To reinstall the top panel, drill a new
d” pilot hole
through the top back panel and into the back panel.
Reinstall the screw P into this new mounting hole.
