Viessmann WB1A007 User Manual

Technical Specification
General Specifications and Performance Data
Rated output range
T
F/TR 50/30 °C kW 8 to 13 8 to 18 8 to 24
T
F/TR 80/60 °C kW 7.3 to 11.8 7.3 to 16.4 7.3 to 21.8
Rated heat load range kW 7.4 to 12.1 7.4 to 16.7 7.4 to 22.3
Maximum gas rate m
3
/h 1.28 1.77 2.36
Minimum CH system pressure
(static head) – Cold
bar 0.2 0.2 0.2
Maximum CH system pressure
(static head) – Hot
bar 1.0 1.0 1.0
Maximum CH flow temperature °C 80 80 80
Lift weight kg 37 37 37
Total weight inc. packaging kg 39 39 39
Electrical supply
230 V,
50Hz
230 V,
50Hz
230 V,
50Hz
Internal fuse A 4 4 4
Maximum power consumption W 55 55 55
Flue outlet (clearance 7): mm 60 60 60
Ventilation pipe (outside 7) mm 100 100 100
Product ID _-0085 BQ 0017
Gas Council Number 41-819-13 41-819-12
41-819-10
Montagevorbereitung (Fortsetzung)
6
Montagevorbereitung
5581 805

Viessmann WB1A007 Specifications

General

Brand	Viessmann
Model	WB1A007
Category	Boiler
Language	English
