ViewSonic CD4620 14
4. To avoid monitor from falling
Take measures to prevent the monitor from falling over in case of an earthquake or other disaster to lessen the probability
of injury and damage resulting from fall.
As shown in the figure, secure the monitor to a solid wall or pillar using rope (commercially available) strong enough to
bear the weight of the monitor. (CD4620: approx. 34.6 kg) When you use screw hooks (commercially available), ring
screw hooks, not C-shaped screw hooks (with opening), are recommended.
Caution:
y The effectiveness of preventing from falling substantially depends on the strength of brackets and base to which
prevention device from falling is attached. When you cannot ensure sufficient strength, provide adequate
reinforcement.
y Though the recommended prevention from falling is intended to lessen the probability of injury and damage, it doesn’t
assure its effectiveness against any kind of earthquake or disaster.
y Do not sleep where the monitor may topple over or fall in case of an earthquake or other disaster.
y Before moving the monitor, remove the rope that is securing the monitor. Failure to do so may result in injury or
breakdown of the monitor.
Screw Holes
Screw hook, etc.
Commercially available
Clamper
Screw
Rope, etc.
Commercially available
* Clamper and Screw is not supply.
