ViewSonic CD4620 User Manual

ViewSonic CD4620 50
Example3: Get Tint from TV-0007 and this command is valid.
The Tint value is 32.
Send (Hex Format)
Name Length ID Command Type Command Value1 Value2 Value3 CR
Hex 0x38 0x30
0x37
0x67
0X65 0x30 0x30 0x30 0x0D
Reply (Hex Format)
Name Length ID Command Type Command Value1 Value2 Value3 CR
Hex 0x38 0x30
0x37
0x72
0x65 0x30 0x33 0x32 0x0D
Example4: Get Tint from TV-07 , but the Brightness command ID is error and it is NOT in the
command table.
Send (Hex Format)
Name Length ID Command Type Command Value1 Value2 Value3 CR
Hex 0x38 0x30
0x37
0x67
0XD7 0x30 0x30 0x30 0x0D
Reply (Hex Format)
Name Length ID Command Type CR
Hex 0x34 0x30
0x37
0x2D
0x0D
PC Get-function command to CD4620/CD4220 LCD Monitor
Length ID Command
Type
Command Response Range Get Function
Code (ASCII) Code (Hex) (Three ASCII bytes)
Comments
Get-Contrast 8 g a 61 000 ~ 100 Gets Contrast value
Get-Brightness 8 g b 62 000 ~ 100 Gets Brightness value
Get-Sharpness 8 g c 63 000 ~ 100 Gets Sharpness value
Get-Color 8 g d 64 000 ~ 100 Gets Color value
Get-Tint 8 g e 65 000 ~ 100 Gets Tint value
Get-Volume 8 g f 66 000 ~ 100 Gets Volume value
000: OFF (unmuted) Get-Mute 8 g g 67
001: ON (muted)
Gets Mute ON/OFF status
000: Disable
001: Enable
Get-RCU 8 g h 68
002: Pass through
Gets RCU mode status
000: Disable Get-Key Pad 8 g i 69
001: Enable
Gets Buttons ON/OFF
status
000: VGA
001: HDMI1
002: HDMI2
003: AV
004: YPbPr
Get-Input select 8 g j 6A
005: S-Video
Gets Input select status
000: STBY Gets the status of the HDTV
power.
001: ON HDTV response:
000 = HDTV is in standby
Get-Power status 8 g l 6C
001 = HDTV is ON
Get-ACK 8 g z 7A 0 This command is used to
test the communication link.
