7. Input Mode
VGA Resolution:
Standard
Resolution
Active Resolution
Refresh Rate Pixel Rate Aspect Ratio Stand for Mode
H Pixels V Lines
VGA 640 480
60 Hz 25.175 MHz
4:3 Video Graphic Array72 Hz 31.5 MHz
75 Hz 31.5 MHz
WVGA 720 400 70 Hz 33.75 MHz 16:9
Wide Video Graphic
Array
SVGA 800
600 60 Hz 40 MHz
4:3 Super VGA
600 75 Hz 49.5 MHz
XGA 1024
768 60 Hz 65 MHz
4:3
Extended Graphic
Array
768 75 Hz 78.75 MHz
WXGA 1280 768 60 Hz 79.5 MHz 5:3 Wide XGA
WXGA 1280 800 60 Hz 79.5 MHz 16:10 Wide XGA
SXGA 1280 960 60 Hz 108 MHz 4:3 Super XGA
SXGA 1280 1024 60 Hz 108 MHz 5:4 Super XGA
WXGA 1360 768 60 Hz 85.5 MHz 16:9 Wide XGA
WXGA 1366 768 60 Hz 85.5 MHz 16:9 Wide XGA
UXGA 1600 1200 60 Hz 162 MHz 4:3 Ultra XGA
HD1080 1920 1080 60 Hz 148.5 MHz 16:9 HD1080
SDTV Resolution:
Standard
Resolution
Active Resolution
Refresh Rate Pixel Rate Aspect Ratio Stand for Mode
H Pixels V Lines
480i
720 480
29.97 Hz 13.5 MHz
4:3
Modied NTSC
Standard
480p 59.94 Hz 27 MHz
576i
720 576
25 Hz 13.5 MHz
4:3
Modied PAL
Standard
576p 50 Hz 27 MHz
HDTV Resolution:
Standard
Resolution
Active Resolution
Refresh Rate Pixel Rate Aspect Ratio Stand for Mode
H Pixels V Lines
720p 1280 720
50 Hz
74.25 MHz 16:9 Normally DVB Mode
60 Hz
1080i 1920 1080
25 Hz
74.25 MHz 16:9 Normally ATSC Mode
30 Hz
1080p 1920 1080
50 Hz
148.5 MHz 16:9 Normally ATSC Mode
60 Hz
• The PC text quality is optimum in HD 1080 mode (1920 x 1080, 60Hz).
• Your PC display screen might appear different depending on the manufacturer (and your particular
version of Windows).
• Check your PC instruction book for information about connecting your PC to a display.
• If a vertical and horizontal frequency-select mode exists, select 60Hz (vertical) and 31.5KHz (horizontal).
In some cases, abnormal signals (such as stripes) might appear on the screen when the PC power is
turned off (or if the PC is disconnected). If so, press the [SOURCE] button to enter the video mode. Also,
make sure that the PC is connected.
• When horizontal synchronous signals seem irregular in RGB mode, check PC power saving mode or
cable connections.
• The display settings table complies with IBM/VESA standards, and based on the analog input.
• The best vertical frequency timing for each mode is 60Hz.

ViewSonic CDE4803-H Specifications

General

Pixel pitch	- mm
Response time	8 ms
Display diagonal	48 \
Display brightness	350 cd/m²
Display technology	LED
Native aspect ratio	16:9
Contrast ratio (typical)	4000:1
Display number of colors	-
Supported graphics resolutions	1920 x 1080 (HD 1080)
DVI port	No
Ethernet LAN	Yes
VGA (D-Sub) input ports	1
Product color	Black
Product design	Digital signage flat panel
Panel mounting interface	200 x 200, 400 x 400 mm
RMS rated power	10 W
Power consumption (standby)	- W

Weight and Dimensions

Depth	59.9 mm
Width	1081.8 mm
Height	623.4 mm
Weight	25400 g
