ViewSonic PF790 11
Other Information
Specifications
CRT
Typ e
Glass surface
19 (18.0 viewable diagonal area). 0.25mm Horizontal,
0.27mm (corner) AG Pitch, 90
o
deflection
Anti-reflecton and anti-static coating
Standard light transmission rate = 40%
Input Signal
Video
Sync
RGB Analog (0.7 Vp-p, 75 Ohms
HV Separate (TTL), Composite, Sync on Green
f
H
: 30-97 kHz, f
v
: 50-180 Hz
Compatibility
PC
Macintosh
®
VGA up to 1600 x 1200
Power Macintosh
®
compatible from 640 x 480 to
1600 x 1200 (may require MAC
®
cable adapter)
Most Workstations (requires optional adapter)
Power
Voltage AC 90-264 V (auto switch) 50/60 Hz
Display Area
Default
Full scan
353 mm (H) x 265 mm (V) (Typical)
364 mm (H) x 275 mm (V) (Depends on signal timing)
Operating
Conditions
Temperature
Humidity
Altitude
32° F to 104° F (0° C to +40° C)
5% to 95% (no condensation)
To 10,000 feet
Storage
Conditions
Temperature
Humidity
Altitude
-40° F to +140° F (-40° C to +60° C)
5% to 95% (no condensation)
To 40,000 feet
Dimensions
Physical
(monitor)
470 mm (W) x 470 mm (H) x 477 mm (D)
18.5" (W) x 18.5" (H) x 18.8" (D)
Weight
Net 23.0 kg (50.6 lb) (monitor only)
Regulations
UL, CSA, FCC-B, CB, DHHS, E2K, TCO99, ICES003,
NOM, TUV/S
Power Saving
Modes
On
Active
Off
< 150 W typical (Green LED)
< 3W (Orange LED)
