Figure1-10 Figure1-11
Figure1-11
1.4 Lamp Wire Arrangement
The Lamp Wire arrangement have to look like the picture as blow.
I. The upper wire fix along the plate. (Figure 1-12)
II. The under wire have to detour the wall of Lamp_Plate.(Figure 1-13)
III. The side wire fix along the plate and have to detour the back wall.(Figure 1-14)
IV. Be sure link up “connecter wire” with “Lamp” correctly (Figure 1-15).
CLIP LAMP UP
CLIP PLATE
M2*4L SCREW
PLATE
M2.5 SCREW
Handle Lamp
