8. PL Module Assembly
8.1 Assemble PL to HSG DMD and fasten screw to fix PL first (Fig 8-1)。
8.2 Assemble “Ring Focus” second (Fig 8-2)。
Figure 8-1 Figure8-2
Ring Focus
Screw *3
