72
ViewSonic Corporation Confidential - Do Not Copy PJ503D-1
7.
EMI Debug Solution Concern
z
All contact fact with conduct fabric isn’t any paint or non-conduct article
z
All contact fact with conduct fabric isn’t any paint or non-conduct article
Item Problem Solution
180 MHz,240MHz,300MHz Add 3 Gaskets
4G.J0C38.001 – 10*5*30 mm
4G.J0C25.001 – 5*5.5*60 mm
4G.J1B12.001 – 10*3.5*58 mm
180 MHz,720MHz
Add spring between lamp case and color
wheel model
3D.01214.001
