ViewSonic PJD5122 Service Manual

Item ViewSonic P/N Ref. P/N Description Q't
y
1
A-00008718
5F.26J1K.261 REMOTE RC-B4020-190 VIEWSONIC 1
2
A-00008253
2G.00921.001 CORD H05VV-F 10A250V EUR 1.8M 1
3
A-00008257
2G.03149.021 CORD H05VV-F 13A 1.8M UK 1
4
A-00008250
2G.01111.001 CORD SVT125V WO/SH US 1.8M 1
5
A-00008193
2G.04321.001 CORD 3ASL/75DU-IN 250V1.8M AUS 1
6
A-00008099
2G.01343.001 CORD H05VV 250V 1.8M BLK KOR 1
7
A-00008100
2G.04245.001 CORD RVV 250V 1.8M BLK CHINA 1
8
CB-00008955
5K.08006.501 CABLE 15/15P OD5.2 1.8M +PEBAG 1
38
M-00008316
6K.0RN10.001 ASSY AIR FILTER MERCURY 1 1
9
DC-00010288
4J.13402.001 GUIDE QS PJD NORMAL MERCU10-2 1
10
DC-00010289
5B.13402.001 CD UM PJD NORMAL MERCURY10-2 1
11
P-00010181
4D.0RN01.031 CTN AB PJD5122/VS 1
12
P-00009419
4G.0RN02.001 CUSHION
_
L PJD5111/VS 1
13
P-00009420
4G.0RN03.001 CUSHION
_
R PJD5111/VS 1
14
P-00009243
4B.01214.031 BAG LDPE+HDPE 415*365*0.4 VS 1
PACKING PART LIST ( PJD5122 )
ViewSonic Model Number: VS13308
Rev: 1a
Confidential - Do Not Copy
PJD5122
ViewSonic Corporation
11

ViewSonic PJD5122 Specifications

General

Projection distance	1.2 - 11.3 m
Vertical scan range	48 - 120 Hz
Horizontal scan range	31 - 100 kHz
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	30 - 300 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	± 40 °
Resolution	1280 x 1024 pixels
Aspect ratio	4:3, 16:9
RS-232 ports	1
Weight (imperial)	5.1 lbs
Dimensions (WxDxH)	264 x 225 x 96.4 mm
Power requirements	100 - 240 V, 50/60 Hz
Connectivity technology	Wired
Lamp power	220 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	6000 h
Focus	Manual
Focal length range	- mm
Full HD	No
HD-Ready	Yes
Analog signal format system	SECAM
RMS rated power	5 W
Audio (L/R) in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	2
Cables included	VGA
Noise level	32 dB
Certification	CB, RoHS, WEEE, UL/cUL, FCC-B, ICES-003, IRAM, NOM, PSB, C-tick, EK, CE, TUV/GS, GOST-R, SASO UKrSEPRO, CCC
Noise level (economic mode)	26 dB
Power consumption (standby)	1 W
Power consumption (typical)	280 W
Operating altitude	1.8 - 3048 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Market positioning	Presentation

Weight and Dimensions

Weight	2300 g
