Connection
When connecting a signal source to the projector, be sure to:
1. Turn all equipment off before making any connections.
2. Use the correct signal cables for each source.
3. Ensure the cables are firmly inserted.
Important
• In the connections shown above, some cables may not be included with the projector
(see "Package contents" on page 2). They are commercially available from electronics
stores.
• The connection illustrations above are for reference only. The rear connecting jacks
available on the projector vary with each projector model.
• For detailed connection methods, see pages 12-19.
1. Audio cable 2. HDMI cable
3. Composite Video cable 4. S-Video cable
5. VGA (D-Sub) to HDTV (RCA) cable 6. VGA cable (D-Sub to D-Sub)
7. USB cable 8. VGA to DVI-A cable
