ViewSonic PJD6243 User Manual

44
RS-232 Command and Configuration
Function Action Control Code Return Code
Power
Power on BE,EF,10,05,00,C6,FF,11,11,01,00,01,00 6
Power off BE,EF,03,06,00,DC,DB,69,00,00,00,00,00 6
Source input
Computer1 BE,EF,03,19,00,19,29,01,47,02,CC,CC,00 6
Computer2 BE,EF,03,19,1E,90,72,01,47,02,CC,CC,00 6
S-Video BE,EF,03,19,00,E8,69,01,47,02,CC,CC,00 6
Video BE,EF,03,19,00,78,A8,01,47,02,CC,CC,00 6
HDMI
BE,EF,03,19,00,DA,2B,01,47,02,CC,CC,00 6
Projector
position
Front table BE,EF,10,07,9F,9D,0E,0A,EF,00,00,00,00 6
Rear table BE,EF,10,07,9F,9D,0E,0A,EF,01,00,00,01 6
Front ceiling BE,EF,10,07,9F,9D,0E,0A,EF,02,00,00,02 6
Rear ceiling BE,EF,10,07,9F,9D,0E,0A,EF,03,00,00,03 6
OSD
Menu BE,EF,02,06,00,E9,D3,30,00,00,00,00,00 6
Up BE,EF,02,06,00,6D,D2,34,00,00,00,00,00 6
Down BE,EF,02,06,00,0B,D2,32,00,00,00,00,00 6
Left BE,EF,02,06,00,DA,D3,33,00,00,00,00,00 6
Right BE,EF,02,06,00,38,D2,31,00,00,00,00,00 6
Lamp
ECO on BE,EF,03,06,00,EF,DB,6A,00,00,00,00,00 6
ECO off BE,EF,03,06,00,3E,DA,6B,00,00,00,00,00 6
Using hours BE,EF,03,06,00,BA,DB,6F,00,00,00,00,00 xxxx
Fan
High Attitude on BE,EF,02,06,00,40,D3,80,00,00,00,00,01 6
High Attitude off BE,EF,02,06,00,40,D3,80,00,00,00,00,00 6
Keystone
Keystone up BE,EF,03,06,00,10,DB,65,00,00,00,00,00 6
Keystone down BE,EF,03,06,00,23,DB,66,00,00,00,00,00 6
Aspect ratio
4:3 BE,EF,03,06,00,0D,DA,68,00,01,00,00,01 6
16:9 BE,EF,03,06,00,0D,DA,68,00,02,00,00,02 6
16:10 BE,EF,03,06,00,0D,DA,68,00,02,00,00,03 6
Auto BE,EF,03,06,00,0D,DA,68,00,02,00,00,00 6
Blank
Blank on BE,EF,02,06,00,DF,DF,66,00,01,00,00,01 6
Blank off BE,EF,02,06,00,DF,DF,66,00,02,00,00,02 6
Freeze
Freeze on BE,EF,02,06,00,02,D0,2B,00,01,00,00,01 6
Freeze off BE,EF,02,06,00,02,D0,2B,00,02,00,00,02 6
Volume
Volume + BE,EF,02,06,00,F1,DE,68,00,00,00,00,00 6
Volume - BE,EF,02,06,00,20,DF,69,00,00,00,00,00 6
Mute on BE,EF,02,06,00,0E,DE,67,00,01,00,00,01 6
Mute off BE,EF,02,06,00,0E,DE,67,00,02,00,00,02 6
Auto source
Auto source on BE,EF,03,06,00,89,DB,6C,00,00,00,00,00 6
Auto source off BE,EF,03,06,00,58,DA,6D,00,00,00,00,00 6
Auto Sync BE,EF,02,06,00,86,D1,2F,00,00,00,00,00 6
Factory default BE,EF,03,06,00,6B,DA,6E,00,00,00,00,00 6
Firmware
version
BE,EF,03,06,00,D5,D9,70,00,00,00,00,00 PXX37-9....
System Status
BE,EF,03,06,00,04,D8,71,00,00,00,00,00 03=Power
On 00=Off
3D Sync
3D Sync on BE,EF,02,06,00,54,EF,7C,00,01,00,00,01 6
3D Sync off BE,EF,02,06,00,54,EF,7C,00,00,00,00,00 6
