ViewSonic VPC100 - Attaching the Stand; Tilting the Screen; Removing the Stand

ViewSonic VPC100
8
Installation
TiltingtheScreen
After installing the stand, the screen can be tilted about 20
o
to suit the user’s preference.
A
B
RemovingtheStand
Should there be a need to detach the stand (i.e., for wall mounting), follow the steps
below:
1. Lay the All-in-One PC on at and stable surface. Use a soft cloth to protect
the display screen.
2. Release screw located on bottom of stand (A).
3. Pull the stand out (B).
AttachingtheStand
1. Lay the All-in-One PC on a at and stable surface. Use a soft cloth to protect
the display screen.
2. Attach the stand. Tighten the stand until it is rmly locked in place.
3. Tighten the screw on the bottom of the stand.
5
o
front and 15
o
back
