7
3. Specification
Model 4 Channel Mobile DVR
In 4 Ch
Video
Out 1 CVBS
In 4 Mic-in
Audio
Out 1 Line-out
Sensor In 2 TTL
Alarm Out 2 Relay
Device
I/O Interface RS232, RS485, USB2.0 x 1, USB1.1 x 1 for Mouse
Speed Real Time
Resolution 720 x 480 (NTSC), 720 x 576 (PAL)
Display
Split Screen 1, 4, PIP, Digital Zoom
Compression H.264 Codec
Speed /
Resolution
120fps@CIF(NTSC)
100fps@CIF(PAL)
60fps@Half D1(NTSC)
50fps@Half D1(PAL)
30fps@D1(NTSC)
25fps@D1(PAL)
Picture Quality Very High, High, Standard, Low
Recording
Mode Time-lapse, Event, Time & Event
Display 1, 4, Digital Zoom
Search Mode Calendar Search, Event Search, Text-In Search, Go to Time
Playback Mode
Multi Channel Normal & Reverse Play,
RW & FF ( x2, x4, x8, x16, x32), Frame to Frame, Pause
Playback
Map Associated Google Map
Interface Ethernet (10/100 Base)
Protocol TCP/IP, HTTP, DHCP, ADSL(PPPoE)
Application Live, Playback, Setup, Notification (Callback, E-Mail)
Network
Web Browse Internet Explorer 7 or higher
Storage Removable Rack (2.5” SATA HDD or SSD & SD Card)
Backup External HDD, USB Memory
Control
USB Mouse,
IR Remote Controller, Joystick Controller
OSD Graphic User Interface (Multilingual)
Approval FCC, CE, KCC
ROHS ROHS Compliance
Power Consumption DC12V~36V, max 64W
Operating Temperature -20°C ~ 50°C / -4°F~122°F (Built-in Heating System)
Operating Humidity 0%~80% / non-condensing
Dimension
225.5(W)x59(H)x245.2(D)mm /
8.87(W)x2.32(H)x9.65(D)inch
Weight 1.63Kg / 3.6lbs (with 250G HDD)
