Radio Receiver
NOTE:
The operator may be supplied with a FA-XR2C Radio Receiver and (2) FA-XT4RC
Transmitters.
FAAC XR2
Terminals
Wiring
Harness
“Radio
Station”
+
RED +28V
-
BLACK GND
COM GREEN GND
N.O. WHITE Radio
STEP 1
Wire the Radio Receiver as illustrated.
! TECHNICAL TIP: The FA-XR2C Radio Receiver is IP44 rated for water
resistance and can mounted outside of the ECU Cabinet.
STEP 2
Program the FA-XT4RC Radio Transmitters to the FA-XR2C Radio
Receiver. Follow the instructions provided with the Transmitters.
ACCESSORY CONNECTIONS
! TECHNICAL TIP: The Control Board provides two modes of operation that a radio
receiver can control the gate. For more information regarding accessory connections
and terminal functions, refer to pages 28-29.
1.
Open-Stop-Close
By having the radio receiver connected as illustrated and with the “Timer” OFF:
This type of configuration is not recommended for commercial installations.
2.
Open Only
By having the radio receiver connected as illustrated and with the “Timer” ON.
