# LED Status Meaning
Page 38
TS Ref#(s)
9 “Power” OFF No power to control board or in Sleep Mode.
1, 6, 15
SOLID Normal Condition.
FLASHING Operator is running on batteries only. (pg 18-19)
1-5
10 “Low Bat” OFF Normal Condition.
SOLID Batteries are low. Check power supply to the operator. (pg 18-19)
1-5
FLASHING Batteries critically low. Check power supply to operator. (pg 18-19)
1-5
11 “Radio Rec” OFF Normal Condition.
SOLID Control Board is receiving an input from a device connected to the
Radio terminal. (pg 28-30)
9, 10
12 “UL Sens” OFF Normal Condition.
SOLID
Control Board is receiving an input from a device connected to the
UL terminal or when more than one required Monitored 10K Sensor is
connected. (pg 6-7, 22, 28)
9, 10, 14
13 “ReOpen Sens”
OFF Normal Condition.
SOLID
Control Board is receiving an input from a device connected to the Re-
Open terminal
or when more than one required Monitored 10K Sensor is
connected.
(
pg 6-7, 22, 28, 32
)
9, 10, 14
14 “Center Loop”
OFF No voltage output on these terminals at the moment.
SOLID An input from a device connected to the Center terminal. (pg
28, 32
)
9, 10
15
“Open”
OFF
Normal Condition.
SOLID An input from a device connected to the Open terminal. (pg
28, 32
)
9, 10
16
“Stop”
OFF
Normal Condition.
SOLID
Control Board is receiving an input from a device connected to the Stop or
has not learned the required monitored sensor(s). (pg
6-7, 22, 28
)
9, 10
FLASHING
There is a problem with the required monitored sensor(s) connected to the
“UL” and/or “ReOpen input terminals. (pg
6-7, 22
)
14
17 “Close” OFF Normal Condition.
SOLID An input from a device connected to the Close terminal. (pg 28)
9, 10
18 “Magnetic Lock” OFF
At Closed Limit and Magnetic Lock Relay state is closed across “COM” &
“N.C.”. (pg 34). Gate should be at the Close Limit.
SOLID
Not at Closed Limit and Magnetic Lock Relay state is closed across “COM” &
“N.O.”. (pg 34). Gate should not be at the Close Limit.
19 “Aux. Pwr” OFF No voltage output on these terminals at the moment.
SOLID There is 24VDC output on these terminals at the moment.
20 “Siren” OFF Normal Condition.
SOLID Second consecutive obstruction has been detected. (pg 24, 26)
1-5, 11-13
FLASHING Batteries are critically low.
1-5
E1
“AC VOLTAGE INPUT”
SOLID Normal Condition.
OFF Incoming power to the optional EMI Board is not sufcient..(pg 19)
2
E2
“PROTECTION WORKING”
SOLID Normal Condition.
OFF
EMI Board is damaged and circuit is not protected. Replace the optional EMI
Board.
E3
“AC VOLTAGE OUTPUT”
SOLID Normal Condition.
OFF There is no output voltage from the optional EMI Board..(pg 19)
2-3
