Learn your Interlude
Threading the Upper Thread
Make sure the presser foot is raised and
the needle is in the up position
1 Pull the spool pin out. Place the
thread on the spool pin and the spool
holder on the spool pin as described.
Push the spool pin back in.
2 Bring the thread in the direction of
the arrow under the thread guide (a)
and over the thread guide (b).
3 Bring the thread down between the
thread tension discs.
4 Continue threading by drawing the
thread from the right into the slot on
the take-up lever.
5 Thread last guide just above the
needle.
6 The needle is threaded from front to
back. The white on the presser foot
ankle makes it easy to see the eye of
the needle.
7 Place thread under the presser foot
and into the thread knife where it is
cut.
Threading for Twin Needle
!
Turn off the main switch.
1 Insert a twin needle.
2 Use a second thread spool or wind a
bobbin with the thread you are going
to use as the second upper thread.
3 LEFT NEEDLE: Thread the machine and
check to ensure that the thread lies
between the inner thread tension discs,
and inside the last thread guide. Thread
the left needle.
4 Attach the extra spool pin onto the
machine. Place a spool holder under
the thread.
5 Place the bobbin with the second
thread on the spool pin.
6 RIGHT NEEDLE: Thread the machine
as before but this thread should lie
between the outer thread tension
discs, outside the lowest thread guide.
Thread right needle.
