Viking VCFB304 - Specifications (30 and 36)

Specifications (Designer All Refrigerator/Freezer)
23
30” All Refrigerator/Freezer
Description DDFB304 DDRB304
Overall Width 30” (76.2 cm)
Overall Height from Bottom
Min. 82 3/4” (210.2 cm) to Max. 84 1/16” (213.5 cm)
Overall Depth from Rear
To front edge of side trim: 23 13/16” (60.5 cm)
To front of top grille: 24” (61.0 cm)
To front of handle: 26” (66.0 cm)
Cutout Width 30” (76.2 cm)
Cutout Height Min. 82 7/8” (210.5 cm) to Max. 84 1/16” (213.5 cm)
Cutout Depth
Min. 24” (61.0 cm)
Electrical Requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum Amp Usage
9.1 amps 5.7 amps
Inlet Water
1/4” copper tubing inlet
Requirements waterline; minimum 20 psi; N/A
maximum 120 psi
Overall Interior Dimensions
Total Capacity 15.9 cu. ft. (450 liters)
18.2 cu. ft. (516 liters)
Approximate Shipping Weight 525 lbs. (236.3 kg) 495 lbs. (222.8 kg)
36” All Refrigerator/Freezer
Description DDFB364 DDRB364
Overall Width 36” (91.5 cm)
Overall Height from Bottom
Min. 82 3/4” (210.2 cm) to Max. 84 1/16” (213.5 cm)
Overall Depth from Rear
To front edge of side trim: 23 13/16” (60.5 cm)
To front of top grille: 24” (61.0 cm)
To front of handle: 26” (66.0 cm)
Cutout Width 36” (91.5 cm)
Cutout Height Min. 82 7/8” (210.5 cm) to Max. 84 1/16” (213.5 cm)
Cutout Depth Min. 24” (61.0 cm)
Electrical Requirements 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum Amp Usage 9.5 amps 6.5 amps
Inlet Water 1/4” copper tubing inlet
Requirements waterline; minimum 20 psi; N/A
maximum 120 psi
Overall Interior Dimensions
Total Capacity 19.1 cu. ft. (541 liters) 22.8 cu. ft. (646 liters)
Approximate Shipping Weight 580 lbs. (261.0 kg) 555 lbs. (249.8 kg)
