Viking VCFB304 - Specifications (Dual)

Specifications (Designer All Refrigerator/Freezer)
31
Dual All Refrigerator/Freezer
Description (2) 30” Units (1) 36” & (1) 30” Unit (2) 36” Units
Overall Width 60” (152.4 cm) 66” (167.6 cm) 72” (182.9 cm)
Overall Height from Bottom
Min. 82 3/4” (210.2 cm) to Max. 84 1/16” (213.5 cm)
Overall Depth from Rear
To front edge of side trim: 23 13/16” (60.5 cm)
To front of top grille: 24” (61.0 cm)
To front of handle: 26” (66.0 cm)
Cutout Width 60” (152.4 cm) 66” (167.6 cm) 72” (182.9 cm)
Cutout Height Min. 82 7/8” (210.5 cm) to Max. 84 1/16” (213.5 cm)
Cutout Depth
Min. 24” (61.0 cm)
Electrical Requirements (2) 115 volt, 60 Hz, 15 amp dedicated circuit; 3-wire cord with
grounded 3-prong plug attached to product
Maximum Amp Usage
30” Freezer 9.1 amps per unit 30” Refrigerator 5.7 amps per unit
36” Freezer 9.5 amps per unit 36” Refrigerator 6.5 amps per unit
Inlet Water
Requirements 1/4” copper tubing inlet waterline; minimum 20 psi;
(All Freezer Only) maximum 120 psi
Overall Interior Dimensions
30” Freezer 15.9 cu. ft. (450 liters)
30” Refrigerator 18.2 cu. ft. (516 liters)
36” Freezer 19.1 cu. ft. (541 liters)
36” Refrigerator 22.8 cu. ft. (646 liters)
Approximate Shipping Weight
30” Freezer 525 lbs. (236.3 kg) each; Refrigerator 495 lbs. (222.8 kg) each
