Viking VCFB304 - Dual 30 Designer Cutout Dimensions

9”
(22.9 cm)
73 3/8”
(186.4 cm)
82–7/8”
(210.5 cm) min
anti-tip board &
opening height
84–1/16”
(213.5 cm) min
anti-tip board &
opening height
60”
(15
2.4
c
m)
24”
(61.0 cm)
Electric Outlet Location
Water Line Entry Area
Note: Cutout opening shown with All Freezer model on left.
Reverse water line entry if All Freezer model is on right.
60”
(152.4 cm)
6–3/
4”
(17.1 c
m)
7–5/8”
(19.4 cm)
3”
(7
.6 cm
)
5
/8”
(1.5 c
m)
5
/8”
(1.5
c
m)
1
0–1/2”
(26.7 cm)
5
/8”
(1.5 cm
)
10–3/4”
(
27.
3 cm
)
3–5/
8
”
(9.2
c
m
)
O
ptional floor
w
ater line entry
1”
(
2.5 cm
)
See Anti-Tip board installation
6”
(15.2 cm)
9”
(22.9 cm)
Cutout Dimensions
(Designer All Refrigerator/Freezer)
32
Dual 30” Designer
