Viking VCFB304 - Hinge Adjustment

44
44
Remove four side screws and remove unit top.
Loosen the four hinge screws. Adjust door.
Retighten four hinge screws.
Replace unit top. Replace four side screws.
Attach one 2x4 to wall stud (refer to dimensions page
for exact location).
If needed, depending on cabinet and depth,
attach second 2x4 to first 2x4.
2
1
5
Front of unit
2
1 3
6
1
2
7
8a
Wall
2 x 4
Refrigerator
8b
Wall
2 x 4
Refrigerator
Hinge Adjustment
