Viking VCFB304 - Door Stop Adjustment; Final Installation

47
3
1
2
20
1
2
21
110˚
90˚
120˚
Open refrigerator door so door stop and shoulder
screw are accessible.
Note: Shoulder screw should be in 110Þ door opening
position.
Remove shoulder screw and place in 90Þ or
120Þ position.
Door Stop Adjustment
Replace top air grille.
Using an 8”magnetic nut driver, replace
the two 1/4” screws.
(Professional) Replace the center grille louver.
(Designer) Replace the center grille louver.
22
23
24a
24b
Final Installation
