Viking VICU206 - Component Testing

© 2009 Viking Preferred Service
23
Component Testing
Component Volts Ohms Amps Test Location
Cooling Fan 12VDC 9150 0.38 X57 on Filter Board
Inductor 240 990 unplugged
708 plugged
N/A Blue wires from inductor
Power Board 240 N/A N/A Black to Blue
Filter Board 240 N/A N/A L1 (X50) and L2 (X52)
Induction Switch N/A
12300 Ω
10000 Ω
91300 Ω
8540 Ω
7800 Ω
3650 Ω
0 Ω
N/A Off terminals 2-3
Simmer terminals 2-3
Low terminals 2-3
Med-low terminals 2-3
Medium terminals 2-3
Med-HI terminals 2-3
HI terminals 2-3
Radiant
VCCU106
Left Rear
Left Front (dual element)
6” Inner
9” Outer
240
37.5 Ω
25.8 Ω
25.8 Ω
N/A
6.25
4.2
10.4
At element
Radiant
VCCU166
Left Rear
Left Front (dual element)
6” Inner
9” Outer
Bridge
240
37.5 Ω
25.8 Ω
25.8 Ω
21.5 Ω
N/A
6.25
3.1
9.1
3.3
At element
Service Diagnostics and Procedures
