44
HVAC
- With or , set the time slot when to change the temperature level.
- With upwards or downwards, select the desired level of temperature from the three available ones
(icons T1, T2 and T3); the histogram will be updated.
Touch C if you want to expand the set level T1,T2 or T3 forwards or backwards; if C is not selected/activated
each movement will not alter the current setting.
- Repeat the procedure for all time slots to be changed, then confirm with Set.
Move onto another day of the week and proceed as above; using Copy from....., it is possible to assign the se-
lected day with the program of any other day of the week; then select the day to copy and touch Set. Save
the configuration with Save.
3.4.2 Setting temperature levels.
HVAC
Setup
Programming zones
Select the HVAC zone
Temperature levels
Select:
Heat. T1 [°C], Heat. T2 [°C],
Heat. T3 [°C] or
Air-con. T1 [°C], Air-con. T2 [°C],
Air-con. T3 [°C]
Insert the desired value and confirm with Set; at the end of the operation touch Save.
The control panel confirms the operation carried out and returns to displaying the page with the settings of the
programs relating to the previously selected temperature zone.
Back Set
Edit Programme
Mon
Fig. 5
Select the zone to be programmed.
HVAC
Setup
Programming zones
Select the HVAC zone
Programs
Select the program to be created:
Heating prog.
Air-conditioning prog.
Select the day associated with the program to make then touch Edit program (Fig. 5).
