1. POWER
This is the main power switch for turning on and
off the device. The amplifier is separated from the
mains voltage when switched off and cannot be
set into a standby state.
2. VU-Meter
These displays show the range in dB and the
direct voltage generated out of the music signal.
This voltage is in accordance with your loudness
sensation.
3. SPEAKER A/B: Buttons to activate/
deactivate the two speaker pairs
If suitable speakers are used, a second speaker
pair may be used simultaneously. With this switch
you can turn loudspeaker outputs A and B on and
off separately. The LED next to the button indica-
tes the active speaker pair.
FRONT VIEW
3 31
2
