Vincent
33
Frequency response: 20 Hz - 20 kHz ±0.5 dB
Nominal Output Power per channel at 8Ω: 150 W
Nominal Output Power per channel at 4Ω: 250 W
Input sensitivity: 1.35 V
Total Harmonic Distortion: < 0.1% (1 kHz, 1 W)
Signal to Noise Ratio: > 91 dB
Input Impedance: 47 kΩ
AC power connection type: 220V – 240V/50 Hz
Inputs: 1x RCA Main Input stereo,
1x XLR Main Input stereo,
1x Power Control (3,5mm Jack)
Outputs: loudspeaker clamps for up to 4
loudspeakers,
1x Power Control (3,5mm Jack)
Dimensions (W x H x D): 426 x 165 x 430 mm
Weight: 21 kg
Colour: silver / black
Tubes: 2x 6N16, 1x 6N15
TECHNICAL SPECIFICATIONS
SEARCH FOR ERRORS
Symptom Possible Cause Countermeasure
Poor sound quality
The cable connections are not tight, the con-
nectors are dirty or a cable is defective.
A
record player has been connected to a line
level input of the preamplifier without using a
phono preamplifier.
An audio source with standard line level out-
p
ut (example: CD player) is connected to the
power amplifier direct input “INPUT” (5).
One speaker pair is connected in bi-wiring,
but not both speaker outputs (SPEAKER A and
B) are activated on the front panel
Check the cables and cable connections.
I
nterconnect a phono preamplifier.
Do not connect line level audio sources at the
i
nput (5).
Turn on both speaker pairs (3).
Humming low fre-
quency noise is
audible, even as
no au dio source is
playing back
See section “Net frequency noise”
in the chapter “Tips”.
See section “Net frequency noise”
in the chapter “Tips”.
