Product name and model
E-bike Intelligent LCD
Model: DR23
Specifications
●36V/48V Power Supply
●Rated working current: 10mA
●The maximum working current: 30mA
●Off-state leakage current: <1μA
●Working temperature:-20°C~ 60°C
●Storage temperature: -30°C~ 70°C
Appearance and Size
Product appearance and dimensional drawing (unit: mm)
*Display side is cable free.
Function and Button Definition
◆Function Summary
DR23 has many functions to meet riders’ needs. The indication elements are as follows：
●Intelligent battery SOC indication
●Motor output power indication
●Assist level selection and indication
●Speed indication (incl. current speed, Max. speed and Avg. speed)
●ODO and Trip
●Push-assistance function and indication
●Trip time indication
●Backlight ON/OFF and indication
●Error code indication
