User’s Manual
Appendix 1 Technical Specifications
Processor 16-bit RISC
Memory 130 kByte FLASH memory for Web pages, updated over the
Internet
Network Interface 10 Mbps RJ45 Ethernet (802.3)
Serial Device Interface Male DB9 connector
Serial port selectable: RS-232 or RS-422/485
Speed selectable: 1 200 - 38 400 bps
Power Requirements 7 – 24 VDC, less than 200 mA
Internet Protocols Supported HTTP 1.1, BOOTP, TFTP, POP3, SMTP, Telnet,
TCP (6 connections), UDP
IP, ICMP, ARP
Ethernet (IEEE 802.3)
Control software
for Windows 95/98/NT/2000
Device’s control database
BOOTP server for set up of IP addresses
TFTP for transferring of Web pages
Dimensions and Weight Models in stainless steel covers:
Size: 65 mm × 75 mm × 27 mm (W×L×H)
Weight: 0.25 kg
Temperature Range Operating temperature: 0 to 70
o
C (32 to 158 F)
Relative Humidity Operating: 5 to 95 % non-condensing
ESERV-10 28 Viola Systems Ltd.
