Appendix A – Specifications
O.S. Embedded Linux 2.6
Multiplex Sixfold operation - simultaneous record, live,
playback, backup, control, & remote access
System
Certification FCC, CE, LVDS, etc.
Format NTSC/EIA or PAL/CCIR
Input 8/4-CH, BNC, 1Vp-p/75ohm
Main monitor BNC x 1, 1Vp-p/75ohm
VGA D-SUB 15-pin connector
3-D de-interlace
& de-noise
Ye s
Loss detection Yes
Video
Motion detection Yes, with configurable detection area & sensitivity
Input 2 RCA-jack connector, line-in level (100mV-2Vrms) Audio
Output 1 RCA-jack connector, line-out level (up to 2Vrms)
Compression Video: H.264
Audio: ADPCM
Frame rate (IPS)
& Resolution
NTSC – 60 / 720*480, 120 / 720*240, 240 / 360*240
PAL – 50 / 720*576, 100 / 720*288, 200 / 360*288
Mode Manual/Schedule/Alarm/Motion
Pre-record time 0 – 10 seconds
Record
Post-record time 0 - 60 minutes
Resolution NTSC – 720*480, PAL – 720*576
Split windows 1/4(/7/9)
Frame rate Up to 30 (NTSC) / 25 (PAL) IPS per display window
Freeze Yes
Sequential switch User adjustable
Display
Digital Zoom X2, X4
Frame rate (IPS)
& Resolution
NTSC – 60 / 720*480, 120 / 720*240, 240 / 360*240
PAL – 50 / 720*576, 100 / 720*288, 200 / 360*288
Search Smart search, Date/time, Camera, Alarm, Motion, &
Video Loss
Playback
Operation Play, Fast Forward, Backward, Pause, Stop, etc.
Remote I.E. and HEM can also Print, Snapshot
HDD
Up to 2 sets of 3.5” SATA HDDs with storage >
2TB/HDD
Advanced format HDD supported
Partitions Configurable alarm partition size
Configurable auto-overwrite or not
Storage
Backup 1 USB 2.0 port for USB 2.0 disk drives, DVD+RW,
DVD+R, DVD-R, card readers, HDD, etc.
Internal DVD models: DVD+RW, DVD+R, DVD-R
Self playback for backup files
Input 4 contact or TTL/CMOS signal, polarity selectable Alarm
(optional)
Output 1 Normally Open or 1 Normally Closed relay output
