ssttaannddaarrdd rreemmoottee ccoonnffiigguurraattiioonnss
1 Auxiliary Channel Out
2 Receive Indicator
3 Signal Indicator
4 Transmit Indicator
5 Lock Status Indicator
6 Unlock Status Indicator
7 Arming Status Indicator
8 Disarming Status Indicator
9 Door Switch Input Indicator
10 Warn Away
®
Response Indicator
11 Siren Status Indicator
12 Trigger Response Indicator
13 Vibrate Mode Indicator
14 Hood Switch Input Indicator
15 Ignition Switch Input Indicator
16 Sensor Response Indicator
17 Sensor 1 Indicator - Full Trigger and Warn Away
®
18 Sensor 2 Indicator - Full Trigger and Warn Away
®
19 Trunk Switch Input Indicator
20 Remote Start Indicator
21 Battery Level Indicator
22 Disarm Button
23 Auxiliary Button
24 Panic Button
25 Arm Button
