4.2 GW1000M Series Ethernet port LED behaviour
The Ethernet port has two physical LEDs, one is green and one is amber. When looking
at the port the green LED is on the left and is the only active LED.
Figure 7: Ethernet LED on the rear of the GW1000M Series router
Link LED
(green)
Off
No physical Ethernet link detected
On
Physical Ethernet link detected
Flashing
Data is being transmitted/ received over the link
Table 4: The Ethernet LEDs activity descriptions
