12.3 Load cell and motherboard replacement
*Any of the following operations need to turn off the power of the electronic
scale and unplug the power cord.
· Load cell replacement steps
：
1
）
Open the bottom plate according to step 12.2, as shown in the figure
：
2
）
The wire sequence of the load cell can be seen as shown in the figure. Unscrew 5
screws to disconnect different wire sequences
：
