Vision REVO User Manual

SHENZHEN CENTER POWER TECH CO., LTD
Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and
Ecological Park, Nanshan District, Shenzhen, China
Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com
Green Our Earth Power Your Vision
27
Table 5.3-1 CBMS panel function definition & description
Item
Name
Description
Remark
1
Dial switch
Set up CBMS ID address
Address field 0-15
2
LAN
LAN interface
update BMS firmware and
monitor software
3
COM
COM1 COM2 interface with GBMS
(Parallel use)
CAN communication
4
Indicator light
Indicates the current working status of
CBMS
Charge and discharge,
static, fault state
5
AC input
CBMS AC power supply interface
AC power supply for
public electricity
6
DC Switch
DC start switch
Startup press at least 3s
7
BMU
Communication
interface
Interface for communication with battery
modules
CAN Communication
interface
8
24V
24V DC output for GBMS power supply
24VDC output and used
for GBMS power supply
9
Breaker
Used to control dc output shutdown
Shunt trip, short circuit
protection function
