7 Cabinet
7.1 Cabinet description
Designed with high strength framework, REVO series Li-ion battery system cabinet meets the
IP20 Criterion. Inside the batteries cabinet, galvanized trails are designed to connect the bus bar and
used in conjunction with galvanized batteries module, which supports the grounding of the cabinet.
Besides, the size is compatible with the standard 19-inch.
7.2 Cabinets specification
Table 7.2-1 Cabinets spec
Item
50AH Cabinet
100AH Cabinet
Commercial Ref ID
LIBVISRAC50AH
LIBVISRAC100AH
Size(W*H*D):mm
600*1000*2000
600*1000*2000
Weight: kgs
120
120
IP Level
20
20
Recommended operating temperature
15- 35°C
15- 35°C
Humility
0~95% non-condensing
0~95% non-condensing
Size with Package
660*1060*2160
660*1060*2160
Weight with Package
135kg
135kg
