10.6 Interconnection inside the cabinet
10.6.1 Module connection
Use the provided power cable to connect as shown in the figure. Wear insulation gloves when
connecting and use insulated torque wrench to tighten the bolts. The standard torque is 35 NM.
Figure 10.6-1 Connect the B+ power cable
