5.5 Breaker
Each CBMS models are equipped with a circuit breaker to control the DC output terminal
(P+/P-/N). The circuit breaker switch can safely disconnect electrical connections with
UPS.
ON：Normally Close circuit breaker: rotate clockwise to Vertical position.
Off：Normally Open circuit breaker: rotate counterclockwise to Horizontal position.
Figure 5.5-1 MCB ON
There are two ways to turn on CBMS, AC and DC.
No matter which way to start, before turning on the CBMS, you should
close the MCCB, and then press the DC or AC button.
1): Close MCCB (Indicate the MCCB with a number)
2) press DC or AC Button indicate the buttons with a number
