As an alternative to cables, copper busbars can be used
Figure 10.6-14 the copper busbar review
10.6.5 GBMS 24V power connection
The GBMS power supply cable is connected from CBMS(dc24v-out) to GBMS (dc24v-in).
Pay attention to the sequence of 24V positive and negative poles to avoid the risk of
burning GBMS, and make sure to tighten the wire with Slotted screwdriver.
The 24V power supply of GBMS is controlled by an isolating switch with
fuse.
