5.4 LED indicator status and definition
LED indicator indicates the current working status of lithium battery system. The
explanation is as follows:
Figure 5.4-1 LEDs
Table 5.4-1 LED Indicator status
Status
Type
Breaker
Status
●
●
Power off
Dormant
●
●
Standby
Normal
●
●
Warning
●
●
Charge
Normal
●
●
Warning
●
●
Protect
●
●
Discharge
Normal
●
●
Warning
●
●
Protect
●
●
Failure
Breaker trip
●
●
