10 Cable Connection
10.1 Connection overview
The system is electrically connected to the UPS, including the lithium system to the bus
cabinet, and the communication cable connection is shown below, take TP200 as example.
One cabinet connection
Figure 10.1-1 connection overview
Cable connection overview includes power cable, communication cable, BMS ID dial
code, etc.
