6 GBMS
6.1 GBMS description
GBMS is the top layer BMS of lithium battery system and an integrated display for the
system. It is responsible for the data collection and processing of its lower layer CBMS.
With real-time analysis, GBMS displays the CBMS operation status on the screen at the
control cabinet level. It interacts with UPS through CAN/RS485/dry contact to ensure the
reliability and safety of the system operation in its life cycle.
6.2 GBMS specification
Table 6.2-1 GBMS spec
Item
Description
Commercial Ref ID
LIBVISGBMS
Dry contact
3 output;1 input
Size(W*H*D):mm
300*170*66
Weight: kg
2.2
Recommended operating temperature
15- 35°C
Operating ambient temperature
0 ~ 40°C
Humility
0~95% non-condensing
Size with Package: mm
355*235*135
Weight with Package:kgs
2.5
