Vision REVO User Manual

SHENZHEN CENTER POWER TECH CO., LTD
Address: Rooms 9-12, 7F, Block B, Building 7, Zone 2, Shenzhen Bay Technological and
Ecological Park, Nanshan District, Shenzhen, China
Tel: 0755-66851118 Fax: 0755-66850678 Email: sales@vision-batt.com
Green Our Earth Power Your Vision
44
Figure 9.2-10 Insulating cap
This insulating caps should keep on the modules terminal until connected
with cables. Please keep the insulating caps of the module properly for
later use when the module needs maintenance.
Figure 9.2-11 Step7: At least two people are needed to move the module into the cabinet for installation.
LIBVISMOD200 battery modules are placed in wooden case

Vision REVO Specifications

General

Technology	Active Shutter
Contrast Ratio	1000:1
Battery Life	40 hours
Battery Type	Rechargeable Lithium-ion
Frame Style	Full Frame
Charging Time	2-3 hours
