VISLINK
Flydrive 120-150 Antenna 14
3.4 ANTENNA STOW CONFIGURATIONS
The antenna may be stowed in its cases in one of two configurations. The first configuration
keeps the cases below the 32kg IATA requirement for air travel, but requires more setup
time. The second quick deployment configuration allows the antenna to be assembled in less
time but results in one case that exceeds 32kg.
Flydrive 120 sub 32 kg configuration
Main antenna case contents:
Antenna base
Antenna stabilising legs and levelling feet
Upper feedarm
Reflector left section
Reflector right section
Segment case contents:
Reflector centre section (with lower feedarm and elevation axis attached)
Reflector top section
Accessory case contents:
Feedhorn cartridge
Roof rack runners and feet (when supplied)
Flydrive 120 quick deployment configuration
Main antenna case contents:
Antenna base
Reflector centre section (with lower feedarm and elevation axis attached)
Segment case contents:
Antenna stabilising legs and levelling feet
Upper feedarm
Feedhorn cartridge
Roof rack runners and feet (when supplied)
Reflector top section
Reflector left section
Reflector right section
