VISLINK
Flydrive 120-150 Antenna i
CONTENTS
AMENDMENT RECORD SHEET 1
EMC DECLARATION 2
WARNINGS AND HAZARDS 3
ADDITIONAL SAFETY INFORMATION 4
STOWAGE WARNING 4
1. ANTENNA 5
1.1 INTRODUCTION 5
2. SPECIFICATION 6
2.1 RF 6
2.2 DRIVE CONTROL UNIT 7
2.3 MECHANICAL 8
2.4 ENVIROMENTAL SPECIFICATION 9
3. OPERATING PROCEDURE 10
3.1 ANTENNA ASSEMBLY – FLYAWAY CONFIGURATION 10
3.2 ANTENNA ASSEMBLY – ROOF RACK MOUNT CONFIGURATION 12
3.3 MANUAL OPERATION 13
3.4 ANTENNA STOW CONFIGURATIONS 14
3.5 OFFSET SATELLITE ADJUSTMENT 18
3.6 DRIVE CONTROL UNIT 18
4. FLYDRIVE MAINTENANCE 19
4.1 DISH 19
4.2 AZIMUTH WORM GEAR 19
4.3 POLARISATION DRIVE 19
4.4 CABLES 19
4.5 FEEDHORN WINDOW 19
4.6 FLEXIBLE WAVEGUIDE 19
4.7 ALL SCREWS/BOLTS 20
4.8 RADIATION CHECK 20
5. ASSEMBLY IMAGES 21
6. WARRANTY 32
6.1 WARRANTY INFORMATION 32
6.2 CLAIM FOR DAMAGE IN SHIPMENT 32
6.3 FIELD SERVICE 32
6.4 SHIPMENT OF REPAIR PARTS TO FIELD 32
6.5 RETURN PROCEDURES 32
6.6 TRANSPORTATION AND PACKAGING 33
6.7 AUTHORISATION FOR EVALUATION 33
7. FIGURES 34
FIGURE 1 – FLYDRIVE 120 CONFIGURATION – 402693 34
FIGURE 2 – FLYDRIVE 120 ROOF RACK MOUNT CONFIGURATION – 402692 34
FIGURE 3 – FLYDRIVE 120 PETAL CASE IN SUB 32 KG CONFIGURATIONS – 402690 35
FIGURE 4 – FLYDRIVE 150 FLYAWAY CONFIGURATION - 403080 36
FIGURE 5 – FLYDRIVE 150 ROOF RACK MOUNT CONFIGURATION - 403080 36
FIGURE 6 – FLYDRIVE 150 PETAL CASE IN SUB 32 KG CONFIGURATIONS 402691 37
FIGURE 7 – FLYDRIVE 150 ANTENNA STOWED - 403080 37
FIGURE 8 – SATELLITE GEOMETRY 38
