VISLINK
Flydrive 120-150 Antenna 16
Flydrive 150 sub 32kg configuration
Main antenna case contents:
Antenna base
Upper feedarm
Feedhorn cartridge
Segment case contents:
Lower:- Reflector centre top section
Reflector left top section
Reflector right top section
Upper:- Reflector left bottom section
Reflector right bottom section
Feedarm flex/twist waveguide (1.3m)
Front roof bars
Thule feet with adjusters x 4
Antenna levelling feet and tool kit
Small segment case contents:
Lower:- Reflector centre section (with lower feedarm and elevation axis attached)
Antenna stabilising legs
Upper:- Cross site waveguide (1.1m)
AC power cable
Rx L band cable
Flydrive 150 quick deployment configuration
Main antenna case contents:
Antenna base
Reflector centre section (with lower feedarm and elevation axis attached)
Segment case contents (this is the same as the quick deploy configuration):
Lower:- Reflector centre top section
Reflector left top section
Reflector right top section
Upper:- Reflector left bottom section
Reflector right bottom section
Feedarm flex/twist waveguide (1.3m)
Front roof bars
Thule feet with adjusters x 4
Antenna levelling feet and tool kit
Small segment case contents:
Lower:- Antenna stabilising legs
