Vislink DVE6100 User Manual

Template Operators Manual
Specifications
Issue No: 1 Page: 11
Ref: DVE6-ASUM-70xx Copyright © 2019 IMT and Vislink are Vislink Technologies Inc. companies
3. Specifications
3.1. Physical
Dimensions
1RU ½ width chassis x 350 mm deep
Weight
1.8 Kg approx.
Power Connector
3-Pin IEC plug with dual fusing
AC Supply
100-240V AC 47 to 63 Hz @ <70 VA
Temperature Range
0 to +50°C (32
o
F to 122
o
F) operating
–20 to +80°C (-4
o
F to 1760
o
F) storage
Humidity
95% max non condensing
Status, HPA Control
15-Way D-type Female
Ethernet Control & IP Video
RJ45
USB Port
Female type A
Video, ASI, Connections
Mini HD SFP / BNC 75R
L-Band RF out, L-Band RF
monitor
N-Type 50R
L-Band RF Combiner
TNC 50R
3.2. Inputs
SDI on SFP
PAL / NTSC serial digital video to ITU-R BT.656 /
ANS I / SMPTE 259M @ 270Mb/s. 16 channels
(eight stereo pairs) embedded audio supported
(only 4 compressed) – 75R
HDSDI on SFP
To SMPTE 292M @ 1.485 Gbit/s
ASI (Re-mux option) [future]
75R to ISO / IEC 13818-2 188bytes
L-Band Combiner
6dB+/-2dB passive coupler into main L-Band
output
3.3. Outputs
L-Band
50R, 950 – 2150MHz +/-0.75dB, +5dBm 40dB
control;
L-Band MONITOR
50R, 30dB+/-3dB less than main L-Band output
ASI
75R, to ISO/IEC 13818-2 188bytes constant rate.
DC on L-band
18V +/-1V @ 1A max.
Precision 10MHz Reference on L-
band
-3dBm min.
