Page #25 background imageLoading...
Page #25 background image
Template Operators Manual
Menu Navigation
Issue No: 1 Page: 25
Ref: DVE6-ASUM-70xx Copyright © 2019 IMT and Vislink are Vislink Technologies Inc. companies
7.1.2. Video
This menu has two sub divisions.
SETTINGS
SDI 1 -4
NOTE: We recommend using the web browser interface to control these settings.
7.1.2.1. Settings
The Settings menus controls the main parameters of the video encoder:
Video Format selects the required video format. See Section 3.5.
Video split mode (applicable to UHD sources only) provides options of:
Quad Split
2 Sample Interleave.
NOTE: Available options depend on the video source.
Encoding Standard defines the encoding mode. This menus provides options of:
MPEG 2
H.264
HEVC
Incorrect Format if incoming video is not the format set on the unit, the unit can
generate video of the correct format as a warning.
Choices are:
Red and moving ball
Red
Black
Network Name This option defines the name entered into the service information
tables.
7.1.2.1.1. Video
The Video menu allows you to enable and disable a channel or use an override.
Parameter
Function
Enabled
Channel active or not.
Bars
Override video input with internally generated bars.
