7.1.7. HPA CONTROL (future option)
To be confirmed.
7.1.8. Unit Setup
Use this menu to setup the general parameters of the DVE6100.
Sub menus are:
 Presets
 Control
 Defaults
 Licenses
 Time & Date
7.1.8.1. Presets
The Presets menu provides storage for up to 200 preset configurations.
Parameter
Function
Preset name
Enter a user-friendly description.
Clear preset name
Erase a stored name.
Recall preset
Choose yes or no.
Store preset
Choose yes or no.
Delete all presets
Choose yes or no.
Copy to USB
Insert USB to front panel socket, and chose yes to save all.
Load from USB
Insert USB and chose yes to load all the preset files to the
unit.
7.1.8.2. Control
Use the Control menu to set the unit control IP address, web page identifier text
and SNMP configuration.
7.1.8.3. Defaults
Use the Defaults menu to restore defaults. Choose Yes to reset the unit to
factory-defined parameters.
Use the Reboot option to restart the unit software without restoring factory
settings.
7.1.8.4. Licenses
Use the Licenses option to enter the license code to Enable/Disable features.
NOTE: When requesting license upgrades, you need to know and supply the
Electronic Serial Number (ESN) to Vislink customer services. See
Section 7.1.9.1 to find your unit serial number.
We advise that you use the web browser method to enter new license codes.
When you enter a new license code, you need to restart the unit so the license
state shows as accepted.
Check the Features page to see the enabled licenses. See Section
7.1.8.5. Time & Date
Use the Time and Date menu to set the time and date in your chosen format.
