Template Operators Manual
Front Panel Overview
Issue No: 1 Page: 16
Ref: DVE6-ASUM-70xx Copyright © 2019 IMT and Vislink are Vislink Technologies Inc. companies
4.5. LEDs
4.5.1. Alarm
This LED illuminates when an internal error occurs. An amber LED indicates a
minor alarm and a red LED indicates a major alarm.
Program the severity of the alarm indication using the unit webpage.
When illuminated indicates power is applied to the unit.
When illuminated green indicates carrier modulation.
When illuminated green indicates the carrier is on.
If this LED is illuminated green, it indicates the HPA has power
applied and that it is functioning. If illuminated red, this
indicates a fault with the HPA.
When flashing amber, HPA is in filament time delay (FTD)
going into standby when warmed up. If flashing green, HPA is
in filament time delay going into transmit when warmed up.
NOTE: FTD is not valid for SSPAs.
