D-303372 TOWER-30AM PG2, TOWER-30AM K9-90 PG2 Installation Instructions 5
B. Put back the cover to return the tamper switch to its normal (undisturbed) position, and then secure the front cover to the base with the
case closure screw.
C. The TOWER-30AM PG2 will enter a 2 min. stability period. During this time the red LED blinks.
D. Walk-test the coverage area - see Figure 4. Walk across the far end of coverage pattern in both directions; the red LED lights each
time your motion is detected followed by 3 LED blinks.
The following table indicates the received signal strength indication.
IMPORTANT! Reliable reception must be assured. Therefore, "poor" signal strength is not acceptable. If you receive a "poor" signal
from the detector, re-locate it and re-test until a "good" or "strong" signal strength is received (in regions requiring UL-compliant
installation, only “strong” signal strength is permitted).
1. For detailed Diagnostics Test instructions refer to the control panel Installer Guide.
2. For UL/CUL installations, the test result must be “Strong”.
4. EVENT INDICATIONS
Stabilization (warm-up 120 sec)
AM detection – diagnostic mode
Yellow LED blinks slowly (0.2 sec. ON, 30 sec. OFF)
AM detection – Normal mode
Yellow and red LED blink simultaneously (0.2 sec. ON [both], 0.2 sec. OFF)
Self-test failure – Diagnostic mode
Yellow and red LED blink simultaneously slowly (0.2 sec. ON [both], 30 sec. OFF)
Self-test failure – Normal mode
5. SPECIAL COMMENTS
Even the most sophisticated detectors can sometimes be defeated or may fail to warn due to: DC power failure / improper connection,
malicious masking of the lens, tampering with the optical system, decreased sensitivity in ambient temperatures close to that of the
human body and unexpected failure of a component part.
The above list includes the most common reasons for failure to detect intrusion, but is by no means comprehensive. It is therefore
recommended that the detector and the entire alarm system be checked weekly, to ensure proper performance.
An alarm system should not be regarded as a substitute for insurance. Home and property owners or renters should be prudent enough
to continue insuring their lives and property, even though they are protected by an alarm system.
6. COMPLIANCE WITH STANDARDS
Europe (CE): EN 50131-1, EN 300220, EN 301489, EN 60950, EN 50130-4, EN 50130-5,
EN 50131-2-2 Grade 3 Class II, EN 50131-6
The TOWER-30 AM PG2 and TOWER-30 AM K9-90 PG2 are compatible with the RTTE requirements -
Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999.
Certified by the Dutch testing and certification body Telefication BV to the following standards :
EN 50131-2-2, EN 50131-6, EN 50131-5-3, EN 50130-4, and EN 50130-5.
Telefication BV has certified only the 868 MHz variant of this product.
UK: This product is suitable for use in systems installed to conform to PD6662:2010 in accordance
with EN 50131-2-2 security Grade 3 and environmental Class 2. DD243 and BS8243
USA: CFR 47 Part 15 (FCC)
Canada: RSS 210
The Power G peripheral devices have two- way communication functionality, providing additional benefits as described in the
technical brochure. This functionality has not been tested to comply with the respective technical requirements and should
therefore be considered outside the scope of the product’s certification.
EN 50131-1 Security Grade
According to EN 50131-1:2006 and A1:2009, this equipment can be applied in installed systems up to
and including Security Grade 2.
EN 50131-1 Environmental
Class
FCC Compliance Statement
Visonic Ltd.
M/N: RFD
FCC ID: WP3RFD
IC: 1467-RFD
